!!!!! Let Megasquirt Unleash the Power of your Engine !!!!!

Note to all Customers we only Supply Genuine B&G Boards.

Megasquirt is a reprogrammable DIY ECU (Engine Control Unit) which is  a great tool if you want to learn about engine control systems, you can buy in Kit form and assemble yourself, all instructions are available in the online Manuals (Manuals) as you are aware if you modify your Engine by fitting high compression pistons, wild cams, multiple throttle bodies, larger injectors, higher fuel pressure, Turbocharge, Supercharge, or just a nice cold ram air induction kit you will want to be able to remap and with most std ECU's this is usually not possible or easy, you can get some piggy back systems that will help but they are not ideal, so this is where Megasquirt comes in as it is a  DIY standalone system that you can modify and tune your fuel and ignition maps as much as you like as you drive with your Laptop connected, and there is loads of help on the MS Forums so you are never left alone if you have a  problem as they are always eager to help, and of course I am only an email: sales@megasquirtuk.co.uk or: Tel 01206 251475 away, but please remember to do your homework as well by reading the online Manuals link above, all ORDERS must be confirmed in WRITING and or EMAIL so all configure details are confirmed before I build your Megasquirt as we do not want to be redooing MODS etc if they are incorrect and that way we both have a record of what was ordered, Thanks. Ok, Regards Eddie Walsh

If you buy an Unassembled Kit from me or anyone else, and decide you do now feel confident or have the time to build your self you can send it to me and I will build and Modify to your spec, £145.00 + Shipping + VAT

To download the latest TunerStudio tuning software click on the link below:

  www.efianalytics.com/TunerStudio/

To help you choose which MS here is a link so you can compare the differences between MS1, MS2, and MS3

http://www.msextra.com/feature-xref.html

Link to MS Extra Forums

PayPal Acceptance Mark

To Pay all you have to do is log on to www.paypal.co.uk and pay sales@megasquirtuk.co.uk Thanks.

ed

Product List and Prices

To order or pay for items we accept Paypal which is a secure way to pay and they accept most Credit Cards, or you can pay by direct Bank Transfer, or by cheque.

To Pay all you have to do is log on to www.paypal.co.uk and pay sales@megasquirtuk.co.uk Thanks.

BTT

The MS 1 V2.2 is a great Value entry level ECU which can run your Fuel Injection, and if you have a 36-1 Crank Trigger Wheel and a VR Sensor, and with some simple mods you can run the Ford EDIS ignition system which can fire your spark plugs in wasted Spark Mode, for  4 - 6 or 8 cycls

MS 1 V 2.2  Unassembled Kit £245.00 + Shipping + VAT

MS1 V2.2 Fully built, 2.5 Bar MAP sensor, good for normally aspirated or Boosted Engines to 30psi max, comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and DB9 cable to connect to your pc, Price £325.00 +  Shipping + VAT.


(Img 1)  (Img 2)

MS 1 V 2.2 Extra Code  Fully assembled and modified, 2.5 Bar MAP sensor, good for normally aspirated or Boosted Engines to 30psi max, modified to run the Ford Edis module and coil pack so will run a 4,6 or 8 cycl wasted spark + your Fuel Injection, comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and DB9 cable to connect to your pc, Price £345.00 + and Shipping + VAT.

_________________________________________

MS 1 V3 Unassembled Kit £295.00 + Shipping + VAT

MS1 V3 Fully Built, Extra Code, 2.5 Bar MAP sensor, good for normally aspirated or Boosted Engines to 30psi max, comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and DB9 cable to connect to your pc, Price £365.00 +  Shipping + VAT.

(Img 1)

MS 1 V 3 Fully Built, Extra Code 2.5 Bar MAP sensor,2.5 Bar MAP sensor, good for normally aspirated or Boosted Engines to 30psi max, modified to run the Ford Edis module and coil pack so will run a 4,6 or 8 cycl wasted spark + your Fuel Injection,comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and DB9 cable to connect to your pc, Price £385.00 + Shipping + VAT.

(Img 1)

BTT


MS 1 V 3 Fully Built, Extra Code 2.5 bar MAP sensor,2.5 Bar MAP sensor, good for normally aspirated or Boosted Engines to 30psi max, and fitted with 2 coil drivers so will run a 4 cycl wasted spark, this is the recommended way as you have complete control of the timing and can also use the onboard rev limiting facility, + your Fuel Injection, comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and DB9 cable to connect to your pc,  Price £410.00 +  Shipping + VAT.

(Img)


MS 1 V 3 Fully Built, Extra Code 2.5 bar MAP sensor, good for normally aspirated or Boosted Engines to 30psi max, and fitted with 3 coil drivers so will run a 6 cycl wasted spark, this is the recommended way as you have complete control of the timing and can also use the onboard rev limiting facility, + your Fuel Injection,comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and DB9 cable to connect to your pc, Price £425.00 + and Shipping + VAT.

  ( Img )

Mazda MX5, 1990-1997 Mazda Miata, or later models by swapping in the 90-97 CAS

Level of control:  Full Standalone EMS-- Fuel and Ignition Control.

Miata, Eunos.1600cc, Megasquirt 1 V3 Extra code loaded, 2.5 bar MAP sensor,2.5 Bar MAP sensor, good for normally aspirated or Boosted Engines to 30psi max, due to popular demand I have now got all the mods done to run the CAS system and the OE coils + your Fuel Injection, so all you have to do is wire it in and tune, comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and DB9 cable to connect to your pc,  Price £445.00 + Shipping + VAT ( also see special Adaptor below)

(Img 1) (Img 2)

Miata, Eunos.1600cc, Megasquirt 2 V3 Extra code loaded, 2.5 bar MAP sensor,2.5 Bar MAP sensor, good for normally aspirated or Boosted Engines to 30psi max, due to popular demand I have now got all the mods done to run the CAS system and the OE coils + your Fuel Injection, so all you have to do is wire it in and tune, comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and DB9 cable to connect to your pc,  Price £525.00 + Shipping + VAT ( also see special Adaptor below)

Adapter Cable as fitted above Eunos 1600cc 1990 this allows you to remove OE ECU and insert OE loom plugs to one end and Megasquirt DB37 to the other end, also includes a short Jumper to insert to MAF plug so you can drive your Fuel Pump through the Adapter cable, £125.00 + Shipping +VAT

(Img 1) (Img 2)

Or if you want to make your own I can supply the 76 pin socket for £25 + VAT

Here is a good link to help with the wiring http://www.miataturbo.net/useful-saved-posts-8/how-make-install-

your-own-diy-megasquirt-13676/

BTT

Megasquirt 1 V3.0 Extra Code loaded, 2.5 Bar Map Sensor, good for upto 30 PSI boost, has got 2 Coil Drivers fitted so can run 4 Cycl Cops in wasted spark mode, they are VW 4 wire COPs which are not included, so ideal for your VW Golf or Audi 20 Valve, or as I have also tried the COPs on my Vauxhall 20XE engine, and all run fine looks a lot better than the old coilpack so chuck that old Distributor and coil pack, + your Fuel Injection,comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and DB9 cable to connect to your pc, Price £425.00 + Shipping + VAT .

(Img 1)

Megasquirt 1 V3.0 Extra Code loaded, 3 Bar Map Sensor, good for upto 40 PSI boost, has got 2 Coil Drivers fitted so can run 4 Cycl Cops in wasted spark mode, they are VW 4 wire COPs which are not included, so ideal for your VW Golf or Audi 20 Valve. Or as I have also tried the COPs on my Vauxhall 20XE engine, and all run fine looks a lot better than the old coilpack so chuck that old Distributor and coil pack,+ your Fuel Injection, comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and DB9 cable to connect to your pc,Price £475.00 +  Shipping + VAT.

(Img 1)

_____________________________________________

BTT

MS 2 V3 Kit unassembled £375.00 + Shipping + VAT

MS2 V3 fully built, 2.5 Bar MAP sensor, 2.5 Bar MAP sensor, good for normally aspirated or Boosted Engines to 30psi max,comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and DB9 cable to connect to your pc,Price £445.00 +  Shipping + VAT.

(Img 1) (Img 2)

Here we have the ultimate Megasquirt 2 V3 Extra which has been modified to run fuel and spark fully sequential for any 4 cycilinder Turbo or supercharged engine, also fitted with MapDaddy 4 bar Map sensor with constant Barometric pressure sensor as well, comes with a set of 4 - 2 wire COP's, also comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and DB9 cable to connect to your pc, Price £845.00 + Shipping + VAT.

Tested this on my Astra GTE 20XE and runs fine,got a resonable Map to get you up and running.


(Img 1 ) (Img 2 ) (Img 3 )

______________________________________________

MS 3 V3 unassembled Kit £545.00 + Shipping + VAT

  MS3 V3 fully built 2.5 Bar Map sensor, 2.5 Bar MAP sensor, good for normally aspirated or Boosted Engines to 30psi max, comes with a resonable MAP to get you up and running, wiring diagram you can download from this site (Link), DB37 Plug, and USB cable to connect to your pc,Price £635.00 +  Shipping + VAT.

(Img 1)

MS 3 Chip (Daughter card) Price £195.00 + Shipping + VAT.

( Img )

MS 3X Expansion Card Price £125.00 +  Shipping + VAT

(Img)

Some SD cards for your MS3 or whatever.

4GB Micro SDHC Card £8 + VAT

8GB Micro SDHC card £12 +VAT

16GB Micro SDHC Card £18 + VAT

32GB Micro SDHC Card £24 + VAT

BTT

Knock Sensor Controller, you will need one of these to connect to your Megasquirt if you want to run a knock sensor Price £125.00 + Shipping + VAT
( Img )

Megastim V2.2 Price (Fully Assembled) £95.00 + shipping + VAT

(Img)

As above unassembled Price £75.00 + shipping + VAT

Jimstim ( Fully Assembled) £155.00 + shipping + VAT

(Img)

As above unassembled Price £125.00 + shipping + VAT

EBC ( Electronic Boost Control ) Solenoid Kit (includes the Mod kit for board) Price £85.00 + Shipping + VAT  (Img)

Bluetooth Adaptor for your Megasquirt 1,2 or 3 with 1 Mtr Cable to plug
straight into your DB9 socket so you can run Shadow Dash on your Android Tablet all set ready to go, Price £65.00 + Shipping + VAT  (Img)

Jaws Wideband Controller with a digital display fully assembled Price £245.00 + Shipping  + VAT

BTT

Megasquirt Relay Board (Fully Assembled) Price £125.00 + Shipping + VAT   (Img)

2 Foot Loom with DB37 plug on each end to connect relay Board to Megasquirt Price £75.00 + Shipping + VAT  (Img)

Or if you want to make your own short or full loom as above I sell the DB37 pin Female solder cups on their own. Price £5.50 each,with solid Metal Hood £6.50, or if you want the light weight plastic hood Price £3.00 each .

MAT or IAT - Manifold Air Temp Sensor ( Open Element) with Plug &connectors ( calibrated for Megasquirt) Price £27.50 +  Shipping + VAT  (Img)


MAT or IAT - Manifold Air temp Sensor (Open Element) not calibrated for MS so you will have to calibrate with Easytherm, Price £22.50 + Shipping + VAT.  (Img)

CLT or water temp sensor with plug and connectors, closed element type, calibrated for Megasquirt, Price £24.50 + Shipping + VAT ( Img )

BTT

5 Foot Labeled Wiring loom ( all labels printed) with DB37 plug already installed and Light Weight Plastic Hood ( so will not damage your MS DB 37 pins when racing on or off road ) Price £115.00 + and Shipping + VAT.

(Img)

1.5 foot ( 460mm) Wiring Pigtails ( all labels printed) and DB37 Plug with Light weight Plastic Hood ( ideal for racing or off road enviroments) suitable for MS 1, 2 or 3 Price £65.00 + Shipping + VAT  (Img)

MS3X 1.5 foot (460mm) Wiring Pigtails ( all labels printed) and DB37 plug with Light Weight Plastic Hood ( Ideal for Racing or Off road enviroments) for all your extra spark and injectior etc outputs Price £65.00 + Shipping + VAT  (Img)

DB37 Plug with 8 inch Tails ( all labels printed) Price £32.50 + Shipping + VAT  (Img)

Or if you want to make your own  loom as above I sell the DB37 pin Female solder cups on their own. Price £5.50 each, and if you also want the light weight plastic hoods. Price £3.00 each + Shipping  + Shipping. (Img)  (Img 2)

BTT

MS 1 Chip Extra Code Loaded Price £58.50 + Shipping + VAT

  MS 2 Chip Extra Code Loaded Price £125.00 + Shipping + VAT  (Img)

MS 3 Chip (Daughter card) Price £195.00 + Shipping + VAT.  (Img)

MAP Sensor 2.5 Bar Price £35.00 + Shipping + VAT  (Img)

MAP Sensor 3 Bar Price £65.00 + Shipping + VAT  (Img)

Map sensor 4 Bar Price £125.00 + Shipping + VAT  (Img)

BTT

 2 Mtr Beldon Shielded cable Ideal for VR Sensor Price £14.50 + Shipping + VAT  (Img)

DB9 Serial Cable 2Mtr ( 6ft) to connect Megasquirt to your PC or Laptop Price £9.50 + Shipping + VAT  (Img)

DB9 Cable for Workshop 5 Mtr Price £14.50 + Shipping + VAT

USB Adapter (that works with Megasquirt) Price £29.50 + Shipping + VAT  (Img)

BTT

Ignition Coil Driver Kits BIP 373 these are the best ones to use if you are replacing or modifying your Megasquirt 1,2, or 3 Price £23.50 + Shipping + VAT

Good used Coil Packs 4 cycl £45 6 cycl Price  £75.00 + Shipping + VAT

Good used TPS Price  £45.00 + Shipping + VAT

Good used Bike Injectors Price  £45.00 each + Shipping + VAT

Aluminium Extrusion to make your own injector rails 4 cycl Price £85.00 + Shipping + VAT  (Img)

As above for 6 cycl Price £110.00 + Shipping + VAT

BTT

We also carry a sellection of Bike Throttle Bodies sizes from 32mm to 42mm  (Img 1)  (Img 2)

We can also Program Blank or Corrupted MS 1 Chips.

Terms: Cash, Postal Orders,Cheques, PayPal. PayPal can accept most Credit/Debit cards, or you can pay by direct Bank Transfer.

To Pay all you have to do is log on to www.paypal.co.uk and pay sales@megasquirtuk.co.uk Thanks.

We can also supply all spares to repair or modify etc.

 Thanks for looking and happy squirting, any questions call or email me . Regards Eddie Walsh
